Next-gen High Use Entrance Doors

Vision 7 is the latest evolution in the Vision range of commercial doors with anti-finger trap technology, making it suitable for a wide range of ground floor applications, including schools and leisure facilities, hospitals, shopping centres and offices.

Heavy duty swing doors with anti finger trap

Slim visual width on bulb style of only 40mm

Achieves Ud value as low as 1.1W/m2K

ConceptSystem 77 multi purpose doors

Vision 7 is Reynaers’ third generation thermal commercial door and framing system, designed for high traffic ground floor entrances in schools, hospitals, leisure facilities, shopping centres and offices. Heavy duty swing leaves with integrated anti finger trap profiles and slim bulb styles give a clean, robust appearance while reducing risk in public spaces.

Behind the slim look is a thermally broken door that achieves U values down to around 1.1 W/m²K, with PAS 24 certified security, tested durability to around one million cycles, and options for panic hardware, burglar resistant variants and multiple threshold solutions to meet accessibility requirements. Efficient production with straight cuts, optimised bar lengths and a post installation adjustable bottom pivot helps keep fabrication time and waste under control.

The ConceptSystem 77 at a glance:

Heavy duty swing doors with integrated anti finger trap profiles for public buildings
Slim visual bulb style, sightlines around 76–84 mm for a clean commercial look
Thermal performance with Ud as low as ~1.1 W/m²K (HI variant)
Max leaf size approx. 3000 mm high × 1250 mm wide, up to 120 kg, glass thickness up to ~50 mm
With options for panic hardware, soft close, concealed hinges, low thresholds and adjustable bottom pivot
